STANDARD
SPECIFICATIONS
- STEERING
WHEEL TAPER DANFOSS 1 ( 1 : 20 - Ø 23,2 ).
- CONNECTION
FOR HYDRAULIC POWER STEERING 16/32" - Z = 12 - M = 1,587.
- ABS
PLASTIC COVERING.
- CONNECTORS
AT THE END OF THE HARNESS AMP CPC SERIES 2 AND 3.
- OTHER
CUSTOMIZED REQUESTS WILL BE CHECKED DURING THE PROJECT DEVELOPMENT
- COMPLETE
OF HARNESS
- TILT
ADJUSTMENT OF 25° (20° TOWARD THE OPERATOR AND 5° TOWARD THE
WINDSHIELD) BY FOOT PEDAL ON THE LEFT SIDE
- TILT
ADJUSTMENT OF 25 ( 10 TOWARD THE WINDSHIELD AND 15 TOWARD THE
OPERATOR) BY A LEVER ON THE RIGHT SIDE
- TELESCOPIC
ADJUSTMENT (80 MM) BY THE SAME LEVER USED FOR THE TILT ADJUSTMENT
-
INSTRUMENTATION
AND ELECTRIC COMPONENTS BY CUSTOMER REQUEST
|
