FEATURES
| Connector | AMP Tyco (Other connectors on request) |
| Display Window | Anti scratch resistant Polycarbonate |
| Communication | CAN 2.0B passive up to 500K |
TECHNICAL DATA
| Housing | Black plastic with bezel black |
| Fixing | U clamps with plastic nuts for panel thickness from 0,5mm to 7mm |
| IP Rating Front | IP65 |
| IP Rating Rear | IP40 |
| Connector | Molex Minifit Jr. - 6 pole |
|
Operating Temperature |
-30°C to +50°C |
|
Storage Temperature |
-40°C to +85°C |
| Humidity | 95% RH (non-condensing) |
| Vibration | EN 60068-2-64 (1g, 10-500Hz)SAE J1378 (20g, 10-80Hz) |
| Temperature Shock |
EN 60068-2-27 (30g, 18ms), EN
60068-2-29 (25g, 6ms) SAE J1378 (55g, 9-13ms) |
| Display |
TN - LCD with backlight 10 bar segment - Battery state of charge 6 numeric digits Display, supports the following modes: - Truck hour meter - Duty truck hour meter - Next truck service - Battery state of charge [%] - Current Failure |
| Operating Voltage | 10-14 VDC Reverse polarity protected |
| Current Consumption | <100mA with blacklight option |
