| P/N | SUPPLY VOLTAGE V | CALIBRATION TABLE NUMBER | SCALE |
DESCRIPTION (BLACK BEZEL, ORANGE POINTER, STANDARD GLASS INSTRUMENTS) |
| 00086.82 | 12 | 1 | 0-4/4 | GRADUATED SCALE FUEL LEVEL GAUGE |
| 00086.69 | 12 | 1 | 40-120°C | GRADUATED SCALE ENGINE WATER TEMPERATURE GAUGE |
| 00086.86 | 12 | 1 | 0-8 bar | GRADUATED SCALE ENGINE OIL PRESSURE |
| 00086.83 | 24 | 1 | 0-4/4 | GRADUATED SCALE FUEL LEVEL GAUGE |
| 00086.79 | 24 | 1 | 40-120°C | GRADUATED SCALE ENGINE WATER TEMPERATURE GAUGE |
| 00086.109 | 24 | 1 | 0-8 bar | GRADUATED SCALE ENGINE OIL PRESSURE |
| 00086.110 | 12 | / | 10-16V | 12V VOLTMETER |
| 00086.111 | 24 | / | 20-32V | 24V VOLTMETER |
| 00086.84 | 12 | 2 | 0-4/4 | GRADUATED SCALE FUEL LEVEL GAUGE |
| 00086.80 | 12 | 2 | 40-120°C | GRADUATED SCALE ENGINE WATER TEMPERATURE GAUGE |
| 00086.85 | 24 | 2 | 0-4/4 | GRADUATED SCALE FUEL LEVEL GAUGE |
| 00086.81 | 24 | 2 | 40-120°C | GRADUATED SCALE ENGINE WATER TEMPERATURE GAUGE |
| 00086.87 | 12/24 | / | / | HOURMETER |
TECHNICAL INFO ABOUT D52 INSTRUMENTS:
- BACKLIGHTED DIAL AND POINTERS
- ANTIROTATION FEATURE AVAILABLE AS STANDARD
AVAILABLE CUSTOMISATIONS:
- THE GAUGES ARE AVAILABLE IN THE STANDARD VERSIONS AS PER PICTURES OR WITH CUSTOMIZED DIAL UPON CUSTOMER REQUEST
- THE POINTERS MAY BE SUPPLIED IN THREE STANDARD COLOURS: RED, WHITE AND ORANGE
- THE D60 GAUGES MAY BE SUPPLIED WITH A SHORT POINTER (21 MM) OR WITH A LONG ONE (28 MM) SEE PICTURE
- THE BEZEL MAY BE SUPPLIED BLACK OR CHROMIUM PLATED
- THE GLASS MAY BE SUPPLIED STANDARD OR WITH ANTIREFLECTION TREATMENT
- THE GAUGES ARE ALSO AVAILABLE WITH A WARNING LIGHT DRIVER BY A LED (D52) OR BY A BULB (D60)
