POSITION SENDER
WORKING TEMPERATURE: -40°C ÷ +80°C - 60 V LOAD DUMP PROTECTED - OUTPUT SHORT
CIRCUIT PROTECTED - REVERSE VOLTAGE PROTECTED - PROTECTION INDEX: IP67 (WHEN
COMPLETE WITH CONNECTOR )
| PN | MAX LOAD CURRENT | FEEDING VOLTAGE | MAX LOAD CURRENT | OPERATING |
| 32.0283.0000 | 50 mA | 12 V | 15 mA MAX ( 12V ) | A |
