BUZZERS
-PROTECTION AGAINST WATER AND
DUST IP65 -WORKING TEMPERATURE -30 C ÷ 80 C
-STORAGE TEMPERATURE -40 C ÷ 85 C
-PROTECTED AGAINST INCORRECT ISTALLATION
| PN | TONE | MINIMUMSOUND PRESSURE cm.80 | OPERATING FREQUENCY | CONNECTION BOARD | VOLTAGE | ABSORBED CURRENT |
| 31.014.000 | PULSE 2Hz+10% | 5V - 70dB - 32V - 80dB | 2.400Hz 500 |  |
5 - 32V | 3 - 18mA |
| 31.017.000 | PULSE
2Hz+10% CONTINUOUS |
5V
- 70dB - 32V - 80dB 5V - 70dB - 32V - 80dB |
2.400Hz
500 2.400Hz 500 |
 |
5
- 32V 5 - 32V |
3
- 18mA 3 - 18mA |
| 31.022.000 | PULSE
2Hz+10% CONTINUOUS |
5V
- 85dB - 32V - 100dB 5V - 85dB - 32V - 100dB |
2.400Hz
500 2.400Hz 500 |
|
5
- 32V 5 - 32V |
3
- 18mA 3 - 18mA |
