| WIRING DIAGRAM | NOMINAL TENSION | NOMINAL D.C. CURRENT | PEAK CURRENT 5" | IP GRADE (IEC 529) | OPERATING TEMPERATURE | THREADING |
 |
12 V | 50 mA | 30 A | IP 67 | - 20° C + 40° C | M 14 x 1,5 |
| 12 V | 10 mA | 20 A | IP 67 | - 20° C + 40° C | M 14 x 1,5 |
|
|
| WIRING DIAGRAM | NOMINAL TENSION | NOMINAL D.C. CURRENT | PEAK CURRENT 5" | IP GRADE (IEC 529) | OPERATING TEMPERATURE | THREADING |
|
12 V | 50 mA | 30 A | IP 67 | - 20° C + 40° C | M 14 x 1,5 |
| 12 V | 10 mA | 20 A | IP 67 | - 20° C + 40° C | M 14 x 1,5 |
