| WIRING DIAGRAM | NOMINAL TENSION | NOMINAL D.C. CURRENT | PEAK CURRENT 5" | IP GRADE (IEC 529) | OPERATING TEMPERATURE |
 |
12 V | 4 A inductive | 30 A | IP 66 | - 20° C + 40° C |
| 24 V | 2 A inductive | 20 A | IP 66 | - 20° C + 40° C |
| WIRING DIAGRAM | NOMINAL TENSION | NOMINAL D.C. CURRENT | PEAK CURRENT 5" | IP GRADE (IEC 529) | OPERATING TEMPERATURE |
|
12 V | 4 A inductive | 30 A | IP 66 | - 20° C + 40° C |
| 24 V | 2 A inductive | 20 A | IP 66 | - 20° C + 40° C |
