| WIRING DIAGRAM | NOMINAL TENSION | NOMINAL D.C. CURRENT | PEAK CURRENT 5" | IP GRADE (IEC 529) | OPERATING TEMPERATURE |
 |
12 V NC | 12 A inductive | 30 A | IP 67 | - 40° C + 85° C |
| 12 V NO | 5 A inductive | 30 A | IP 67 | - 40° C + 85° C | |
| 24 V NC | 8 A inductive | 20 A | IP 67 | - 40° C + 40° C | |
| 24 V NO | 3 A inductive | 20 A | IP 67 | - 40° C + 85° C |
