| WIRING DIAGRAM | NOMINAL TENSION | NOMINAL D.C. CURRENT | PEAK CURRENT5" | IP GRADE(IEC 529) | OPERATING TEMPERATURE | REMOVABLE HANDLE |
 |
12 V | 250 A | 2500 A | IP 65 | - 40° C + 80° C | 13.007.005 |
| 24 V | 250 A | 2500 A | IP 65 | - 40° C + 80° C | 13.007.005 |
| WIRING DIAGRAM | NOMINAL TENSION | NOMINAL D.C. CURRENT | PEAK CURRENT5" | IP GRADE(IEC 529) | OPERATING TEMPERATURE | REMOVABLE HANDLE |
|
12 V | 250 A | 2500 A | IP 65 | - 40° C + 80° C | 13.007.005 |
| 24 V | 250 A | 2500 A | IP 65 | - 40° C + 80° C | 13.007.005 |
