| WIRING DIAGRAM | NOMINAL TENSION | NOMINAL D.C. CURRENT | PEAK CURRENT 5" | IP GRADE (IEC 529) | OPERATING TEMPERATURE | FIXED HANDLE |
 |
12 V | 250 A | 2500 A | IP 66 | - 40° C + 80° C | X |
| 24 V | 250 A | 2500 A | IP 66 | - 40° C + 80° C | X |
| WIRING DIAGRAM | NOMINAL TENSION | NOMINAL D.C. CURRENT | PEAK CURRENT 5" | IP GRADE (IEC 529) | OPERATING TEMPERATURE | FIXED HANDLE |
|
12 V | 250 A | 2500 A | IP 66 | - 40° C + 80° C | X |
| 24 V | 250 A | 2500 A | IP 66 | - 40° C + 80° C | X |
