| 09.005.000 | 09.007.000 | 09.055.000 | |||
 |
 |
 |
|||
| TRANSMISSION
OIL LOW PRESSURE - TRANSMISSION OIL LEVEL - NEUTRAL - FUEL RESERVE |
|||||
| 09.056.000 | 09.058.000 | 09.059.000 | |||
 |
 |
 |
|||
| DIFFERENT
LOCK - WORK HEADLIGHT ENGINE OIL LEVEL - FRONT DRIVE ON |
GENERATOR
LOAD - OIL PRESSURE DRIVING BEAM - DIMMER |
1ST
TRAILER - 2ND TRAILER DIRECTION DIRECTION INDICATOR - NEUTRAL |
|||
| 09.067.000 | 09.068.000 | 09.069.000 | |||
 |
 |
 |
|||
| POWER
TAKE-OFF ON - BODY RAISING REAR FOG LAMP - FOG LAMP |
DRIVING
BEAM - POSITION LIGHTS HAZARD - HANDBRAKER ON |
DIRECTION
INDICATOR - REAR FOG LAMP STARTER - GENERATOR CHARGE |
|||
| 09.071.000 | 09.072.000 | 09.077.000 | |||
 |
 |
 |
|||
| CENTRIFUGE
OFF - STRAW HAY CUTTER MACHINE ENGEGE HYDRAULIC CIRCUIT OIL FILTER HYDROSTATIC TANK OIL LEVEL |
HAZARD
- MAX WATER TEMPERATURE PREHEATING - BRAKE OPERATOR ENGAGE |
GENERATOR
LOAD - OIL PRESSURE - CONVERTER OIL HIGH TEMPERATURE - AIR CLEANER OBSTRUCTION |
|||
| 09.078.000 | 09.140.000 | 09.144.000 | |||
 |
 |
 |
|||
| POSITION
LIGHTS - TURN DIRECTION INDICATOR HAND BRAKE ON - FRONT DRIVE ON |
HAZARD-TRAILER UNHOOKING ENGINE PREHEATING-BRAKE OPERATOR ENGAGED | FUEL
RESERVE - TRACTORS DIRECTION HAND BRAKE ON - HAZARD WARNING |
|||
| 09.145.000 | 09.149.000 | 09.150.000 | |||
 |
 |
 |
|||
| GENERATOR
LOAD - ENGINE OIL LOW PRESSURE SIDE MARKER LAMPS - CRIVING BEAMS |
NEUTRAL | GENERATOR
LOAD - ENGINE OIL LOW PRESSURE ENGINE PREHEATING - HAND BRAKE ON |
|||
| 09.152.000 | 09.154.000 | 09.155.000 | |||
 |
 |
 |
|||
| POSITION
LIGHT - DRIVING BEAMS FOG HEAD LAMP - REAR FOG |
HYDRAULIC
OIL PRESSURE - PARKING BRAKE FUEL RESERVE - NEUTRAL |
POSITION
LIGHT - DRIVING BEAMS TRACTORS DIRECTION - TRUCK DIRECTION INDICATOR |
|||
| 09.156.000 | 09.157.000 | 09.160.000 | |||
 |
 |
 |
|||
| HYDRAULIC
OIL PRESSURE - HYDROSTATIC POMPE OIL PRESSURE - HYDROSTATIC CIRCUIT OIL TEMPERATURE HYDROSTATIC FILTER OIL PRESSURE |
GENERATOR
LOAD - ENGINE OIL LOW PRESSURE WATER MAX TEMPERATURE - ENGINE PREHEATING |
DIFFERENTIAL
LOCK - WORK HEADLIGHT TRAILER BRAKES - FRONT DRIVE ON |
|||
| 09.161.000 | 09.163.000 | 09.165.000 | |||
 |
 |
 |
|||
| HIGH MEDIUM LOW NEUTRAL |
HYDROSTATIC POMPE OIL PRESSURE TRAILER BRAKES - NEUTRAL- FUEL RESERVE | PREHEATING
- WATER MAX TEMPERATURE - HYDROSTATIC CIRCUIT OIL TEMPERATURE - ENGINE OIL LOW PRESSURE |
|||
| 09.169.000 | 09.170.000 | 09.175.000 | |||
 |
 |
 |
|||
| FRONT
DRIVE ON - TRAILER BRAKE - HYDROSTATIC POMPE OIL PRESSURE - DIFFERENTIAL LOCK |
GENERATOR
LOAD - DIFFERENTIAL LOCK SHAKER - DIRECTION INDICATOR |
GENERATOR
LOAD - ALL WHEEL DRIVE POWER TAKE-OFF ON - DIRECTION INDICATOR |
|||
| 09.176.000 | 09.177.000 | 09.182.000 | |||
 |
 |
 |
|||
| NEUTRAL | NEUTRAL | HYDRAULIC
BRAKES OIL - WATER TEMPERATURE ENGINE OIL PRESSURE - BATTERY LOAD |
|||
| 09.183.000 | 09.184.000 | 09.185.000 | |||
 |
 |
 |
|||
| LEFT INDICATOR - DRIVING BEAMS PARKING BRAKE - RIGHT INDICATOR |
BATTERY
- OIL PRESSURE CLOGGED AIR FILTER - PREHEATING |
OIL
TEMPERATURE - HYDRAULIC OIL PRESSURE PARKING BRAKE - NEUTRAL |
|||
| 09.186.000 | 09.188.000 | 09.189.000 | |||
 |
 |
 |
|||
| DIRECTION
LIGHTS - BRAKES OIL LOW LEVEL DIMMERS - DRIVING BEAMS |
STOP | GENERATOR
LOAD - ENGINE OIL PRESSURE AIR FILTER ABSTRUCTION - ENGINE PREHEATING |
|||
| 09.190.000 | 09.191.000 | 09.192.000 | |||
 |
 |
 |
|||
| HYDROSTATIC
CIRCUIT OIL TEMPERATURE HYDRAULIC OIL PRESSURE - PARKING BRAKE - NEUTRAL |
DIRECTION
LIGHTS - PRESSURE BREAKE OIL POSITION LIGHTS - DRIVING BEAMS |
DIMMERS
- DRIVING BEAMS POSITION LIGHTS - DIRECTION INDICATOR |
|||
| 09.193.000 | 09.197.000 | 09.198.000 | |||
 |
 |
 |
|||
| LEFT
INDICATORS - POWER TAKE OFF DRIVING BEAMS - RIGHT INDICATORS |
NEUTRAL | NEUTRAL | |||
| 09.0292.0000 | 09.0295.0000 | 09.0296.0000 | |||
 |
 |
 |
|||
| LEFT INDICATORS - DRIVING BEAMS - HAZARD - RIGHT INDICATORS | FORWARD DIRECTION - BACKWARD DIRECTION - FRONT WHEEL SUSPENSIONS BLOCKING - REAR WHEEL SUSPENSIONS BLOCKING | ENGINE OIL PRESSURE - GENERATOR LOAD - CONVERTER OIL HIGH TEMPERATURE - TRANSMISSION OIL PRESSURE | |||
| 02.0299.0000 | 02.1200.0000 | ||||
 |
 |
||||
| ABS - ABS TRACTOR - PARKING BRAKE - TELMA | LOCKED DIFFERENTIAL LOCK - FRONT DRIVE ON FOG HEADLAMP - REAR FOG | ||||
