| 09.450.000 | 09.451.000 | 09.452.000 | 09.453.000 | 09.454.000 | |||||
 |
NEUTRAL |  |
NEUTRAL |  |
NEUTRAL |  |
NEUTRAL |  |
NEUTRAL |
| 09.455.000 | 09.456.000 | 09.457.000 | 09.458.000 | 09.459.000 | |||||
 |
NEUTRAL |  |
GENERAL LIGHTING |  |
GENERATOR LOAD |  |
DRIVING BEAMS |
 |
TRACTORS DIRECTION |
| 09.460.000 | 09.461.000 | 09.462.000 | 09.463.000 | 09.464.000 | |||||
 |
HAZARD |  |
ENGINE PREHEATING |  |
AIR BRAKES LOW PRESSURE |
 |
ENGINE OIL LOW PRESSURE |
 |
TRANSMISSION OIL HIGH TEMPERATURE |
| 09.465.000 | 09.466.000 | 09.467.000 | 09.468.000 | 09.469.000 | |||||
 |
ADDITIONAL HEATER |  |
SIDE MARKER
LAMPS U.S.A. |
 |
BELT BREAKING |  |
FUEL |  |
AIR TRAILER LOW PRESSURE |
| 09.470.000 | 09.471.000 | 09.472.000 | 09.473.000 | 09.474.000 | |||||
 |
DIFFERENTIAL LOCK |  |
TRAILERS DIRECTION |  |
HAND BRAKE ON |  |
CABS OVERTURN |  |
RUNWAY SPEED RATE |
| 09.475.000 | 09.476.000 | 09.477.000 | 09.478.000 | 09.479.000 | |||||
 |
HYDRAULIC BRAKES AVERAGE |
 |
MAX WATER TEMPERATURE |
 |
REAR FOG |  |
REAR MIRROW
VISION HEATING |
 |
AXLE BRIDGE
BRAKE AIR LOW PRESSURE |
| 09.480.000 | 09.481.000 | 09.482.000 | 09.483.000 | 09.484.000 | |||||
 |
BRIDGE BRAKES
AIR LOW PRESSURE |
 |
BRAKES AVERAGE |  |
OPEN DOOR |  |
OPEN DOOR 1 |  |
OPEN DOOR 2 |
| 09.485.000 | 09.486.000 | 09.487.000 | 09.488.000 | 09.489.000 | |||||
 |
OPEN DOOR 3 |  |
STOP REQUEST |  |
FAST GEARS |  |
SLOW GEARS |  |
CLUTCH WEAR |
| 09.490.000 | 09.491.000 | 09.492.000 | 09.493.000 | 09.494.000 | |||||
 |
CLOGGED AIR CLEANER |  |
POWER TAKE-OFF ON |  |
BRAKE WEAR |  |
3RD AXLE RAISING |  |
DUMP BODY |
| 09.495.000 | 09.496.000 | 09.497.000 | 09.498.000 | 09.499.000 | |||||
 |
VEHICLE RAISING |  |
FORCED BLOWING |  |
TRAILER UNHOOKING |  |
LOADING FLOOR LIGHTING |
 |
BRAKE FLUID LOW LEVEL |
| 09.500.000 | 09.501.000 | 09.502.000 | 09.503.000 | 09.504.000 | |||||
 |
REFRIGERATON ON |  |
FOG HEADLAMP |  |
POWER TAKE-OFF |  |
ASPIRATOR |  |
ELECTROFAN |
| 09.505.000 | 09.506.000 | 09.507.000 | 09.508.000 | 09.509.000 | |||||
 |
INTERN HEATING |  |
1ST PERIOD
ENGINE PREHEATING |
 |
2ST PERIOD
ENGINE PREHEATING |
 |
CONDITIONER |  |
SAFETY BELT |
| 09.510.000 | 09.511.000 | 09.512.000 | 09.513.000 | 09.514.000 | |||||
 |
LONGITUDINAL DIFFERENTIAL LOCK |
 |
ELECTRICAL DECELERATOR |
 |
BEACON |  |
FRONT BRIDGE DIFFERENTIAL LOCK |
 |
REAR DRIVE |
| 09.515.000 | 09.516.000 | 09.517.000 | 09.518.000 | 09.519.000 | |||||
 |
LOCKED
DIFFERENTIAL LOCK |
 |
FRONT DRIVE ON |  |
ALTERNATECURRENT ON BOARD |
 |
RECHARGED DRIVE BATTERY |
 |
BRAKE WEAR |
| 09.520.000 | 09.521.000 | 09.522.000 | 09.523.000 | 09.524.000 | |||||
 |
CONVERTER ON |  |
OIL CONVERTER PRESSURE |
 |
OIL CONVERTER TEMPERATURE |
 |
INSUFFICIENT
BRAKE PRESSURE |
 |
BRAKE LIQUID LOW LEVEL |
| 09.525.000 | 09.526.000 | 09.527.000 | 09.528.000 | 09.529.000 | |||||
 |
PARKING BRAKES |  |
MECHANICAL
GROUPS DIFFERENTIAL LOCK |
 |
OPEN MATCH COVER |  |
POWER TAKE-OFF |  |
FRONT
BRIDGE DIFFERENTIAL LOCK |
| 09.530.000 | 09.531.000 | 09.532.000 | 09.533.000 | 09.534.000 | |||||
 |
AVERAGE
SUSPENSION SYSTEM |
 |
SENDER |
 |
RADIO TELEPHONE |
 |
OBLITERATER |  |
SIGNES LIGHTING |
| 09.535.000 | 09.536.000 | 09.537.000 | 09.538.000 | 09.539.000 | |||||
 |
BRAKES PRE-WEAR |  |
LATERAL RIGHT THERMIC GLASS |
 |
ELECTRICAL
HEATING OF WINDSCHIELD DEFROSTER |
 |
AVERAGE REPEATER |  |
ENGINE WATER LOW LEVEL |
| 09.540.000 | 09.541.000 | 09.542.000 | 09.543.000 | 09.544.000 | |||||
 |
OPEN HATCH COVER |  |
AIR SPRINGS LOW PRESSURE |
 |
PARKING BRAKE |  |
TRACTOR ABS
SAFETY LAMP |
 |
TRACTOR ABS
SAFETY LAMP |
| 09.545.000 | 09.546.000 | 09.547.000 | 09.548.000 | 09.549.000 | |||||
 |
ABS INFORMATION LAMP |  |
TOOLS BOX LIGHTING |  |
BEACON |  |
POWER TAKE-OFF ON |  |
SPEED LIMITING DEVICE |
| 09.850.000 | 09.851.000 | 09.852.000 | 09.853.000 | 09.854.000 | |||||
 |
EXTERNAL LAMPS |  |
HYDRAULIC BRAKE |  |
ALL WHEEL DRIVE |  |
STOP REQUEST |  |
STOP BRAKE |
| 09.855.000 | 09.856.000 | 09.857.000 | 09.858.000 | 09.859.000 | |||||
 |
GENERAL CURRENT SWITCH CUF OFF |
 |
DRIVER VENTILATION |  |
LONGITUDINAL DIFFERENTIAL LOCK |
 |
ENGINE OIL HIGH TEMPERATURE |  |
BILGE PUMP |
| 09.860.000 | 09.861.000 | 09.862.000 | 09.863.000 | 09.864.000 | |||||
 |
ENGINE HIGH TEMPERATURE |
 |
POWER TAKE-OFF ON |  |
DIFFERENTIAL LOCK |  |
FRONT BRIDGE
BRAKE AVERAGE |
 |
REAR BRIDGE
BRAKE AVERAGE |
| 09.865.000 | 09.866.000 | 09.867.000 | 09.868.000 | 09.869.000 | |||||
 |
3RD AXLE RAISING |
 |
MECHANICAL
GROUPS DIFFERENTIAL LOCK |
 |
POWER TAKE-OFF |  |
FRONT BRIDGE DIFFERENTIAL LOCK |
 |
STARTER |
| 09.870.000 | 09.871.000 | 09.872.000 | 09.873.000 | 09.874.000 | |||||
 |
HEATING FAN |  |
HYDRAULIC OIL LEVEL |  |
PUMP ENGAGED |  |
OPENED GATE |  |
HASPEL ON |
| 09.875.000 | 09.876.000 | 09.877.000 | 09.878.000 | 09.879.000 | |||||
 |
REAR FOG LAMP |  |
RAISED LAMPS CULUMN |  |
MOVEMENT TAKE-OFF |  |
THERMIC REAR WINDOW |  |
TRANSMISION OIL FILTER |
| 09.913.000 | 09.914.000 | 09.915.000 | 09.916.000 | 09.917.000 | |||||
 |
SEMITRAILER
AXLES RAISING |
 |
CONVERTER ON |  |
CONVERTER OIL MAX. TEMPERATURE |
 |
HYDROGUIDE |  |
FRONT
SEMITRAILER AXLES RAISING |
| 09.918.000 | 09.919.000 | 09.920.000 | 09.921.000 | 09.922.000 | |||||
 |
REAR SEMITRAILER AXLES RAISING |
 |
TYRES INFLATION |  |
AXLE LOCKING |  |
SPEED LIMITING DEVICE |
 |
AXLE LOCKING |
| 09.927.000 | 09.928.000 | 09.929.000 | 09.930.000 | 09.931.000 | |||||
 |
HYDROSTATIC OIL FILTER |
 |
WATER IN THE GASOLINE FILTER |
 |
DIMMERS |  |
AIR LOW PRESSURE |
 |
OPEN DOOR |
| 09.932.000 | 09.933.000 | 09.934.000 | 09.935.000 | 09.936.000 | |||||
 |
LUX CONTROL LIGHT |
 |
P.T.O. OFF |  |
TRACTORS DIRECTION |
 |
1ST TRAILER DIRECTION |
 |
2ST TRAILER DIRECTION |
| 09.937.000 | 09.938.000 | 09.939.000 | 09.940.000 | 09.942.000 | |||||
 |
HASPEL |  |
TIPPER UP |  |
INDIPENDENT STEERING WHEELS |
 |
2ND STEERING WHEEL |
 |
ENGINE SHUTDOWN |
| 09.943.000 | 09.944.000 | ||||||||
 |
DIFFERENTIAL LOCK |  |
FRONT POWER TAKE-OFF |
||||||
